One of the central tasks pursued by the lab team rests in investigating modern advanced methods for detecting partial discharges in power equipment (typically transformers) via monitoring the electromagnetic emission in the ultrashort wave band (300 MHz - 3 GHz). The approach facilitates determining the severity of their discharge activity and localizing the critical point of origin at a high degree of accuracy. The team have developed a unique diagnostic system that is used in the operational diagnostics of transformers at the Dukovany nuclear power plant.
Room: SC3.82
Main activities
- Investigating high-frequency measurement and diagnostics systems and power sources
- Developing components for physical quantity sensors operating in the radio frequency to microwave regions
Laboratory equipment
- Shielded anechoic chamber
- High-frequency modulated generators, 3 – 6 GHz
- Pulse-pattern programmable high-frequency generator with a dual synchronous output, up to 240 MHz
- Spectrum analyzers, up to 6 GHz
- Dual port vector network analyzer, 9 kHz - 6 GHz
- Computer-based impedance/network analyzer, 1 Hz – 40 MHz
- Four-channel memory oscilloscope, 3 GHz, 20 Gsa/s
- High-frequency passive, active, voltage, and current oscilloscope probes
